The new Excel Drive System contributes to the Precedent i2’s best-in-class performance. Featuring:

Low Motor Braking Speed
Minimum motor braking speed to almost zero. Motor braking down to a very low speed improves vehicle control and convenience by allowing the driver to adjust both speed and braking with the accelerator pedal. Better control leads to improved stability and adds to the overall driving and riding experience.

Hill Descent Assist
Provides more control and confidence when descending hills by allowing the driver to choose downhill speed with the accelerator pedal. Also prevents sudden acceleration when the park brake is released on a slope thus resulting in a smoother launch.

Increased Regenerative Braking
Dramatic increase in regenerative energy recovery as a result of low motor braking. When used properly, this feature can reduce utility costs in comparison to prior models.

Peace of Mind with Mechanical Brakes
Motor braking delivers a smooth, controlled braking experience and when combined with the reliability of mechanical drums, offers the driver assurance and comfort with a traditional pedal feel and usage. The balance between motor and mechanical braking, increases brake pad life and decreases maintenance.

Performance
System maintains best-in-class acceleration and hill-climbing and allows for enhanced top speed control which ensures for a smooth ride on those courses with rolling terrains.

Speed Programmability
Operators now have more options when programming the speed range of their cars to meet the needs and design of their course. Ranges now include speeds from 5-19.2mph and fine adjustments of 0.1 mph increments.

Power
Power Source Electric
Horsepower 3.3 hp
Batteries (4) 12-volt Trojan Batteries
Charger 48V variable with on-board computer


Agility
Power Source Electric
Steering Self-compensating double reduction helical rack and pinion
Suspension Independent leaf spring with dual hydraulic shocks
Brakes Mechanical drum brakes on rear wheels
Park Brake 3-position


Strength / Design
Power Source Electric
Frame Chasis Ladder-style aluminum box beam
Body Formion®
Body Color Molded in
Tires 18 x 8.50 — 8
Overall Length 91.5in (232 cm)
Overall Width 47.25in (120 cm)
Overall Height 68.5in (174 cm)
Wheelbase 65.5in (166.4in)
Ground Clearance 4.5in (11.4 cm)
Tread (Front/Rear) 34.5in/38.6in (87.6in/97.8cm)
Dry Weight Less Batteries 495 lb. (224.5kg)
Speed Range 7 speed settings: 8 to19 mph; 4 acceleration settings: Aggressive or traditional; 5 pedal-up braking settings: None, mild and aggressive.
Vehicle Warranty 4-year: batteries (20,000 energy units or 1,000 rounds), canopy, electronics, pedal group, seats, suspension. 3-year: body panels, electric powertrain. 2-year: all remaining components. Limited lifetime: frame
